Vaizdo/garso įvestis
| IP kamera | 4-ch connected via PoE interfaces and 4-ch extendable via PoE switch.4 |
|---|---|
| Dvipusis garsas | 1, integrated in EXT.DEV interface |
Vaizdo/garso išvestis
| Vaizdo išvestis | Main output: 1, integrated in EXT.DEV interface VGA: 1 |
|---|---|
| Garso išvestis | 1, integrated in AVOUT of EXT.DEV interface2 |
Talpykla
| HDD/SSD | 2 × 2.5 inch HDD/SSD, up to 2 TB for each HDD/SSD,A dummy HDD with USB 3.0 interface |
|---|---|
| SD kortelė | 1 × SD card, up to 256 GB |
Išorinė sąsaja
| Tinklo sąsaja | 1 × 10M/100M RJ45 Ethernet interface 1 × 10M/100M 12M 6-pin aviation connector (Non-PoE) |
|---|---|
| USB sąsaja | Front panel: 1 × USB 2.0 Rear panel: 1 × USB 2.0 (5-pin aviation connector) |
| Įspėjamojo signalo įvestis | 4 high/low level signal inputs, 1 pulse signal input, 1 BUTTON input |
| Įspėjamojo signalo išvestis | 2 relay signal outputs |
| Serijinis prievadas | 1 × RS-232, 1 × RS-422 |
| Sensorius | 4 high/low level signal inputs |
Belaidis tinklas
| 3G/4G sujungimas | WCDMA/TDD-LTE/FDD-LTE modules are supported. 1 × 3G/4G card slot, 1 × Rosenberger antenna |
|---|---|
| Wi-Fi | 802.11b/g/n and 802.11ac are selectable. 1 antenna is needed for 802.11b/g/n module. 2 antennas are needed for 802.11ac module1 × 2.4 G Wi-Fi SMA antenna |
Pagrindinis
| Veikimo temperatūra | Device that provides dummy HDD with heating function: -30 °C to +60 °C (-22 °F to +140 °F) Other devices: -10 °C to +60 °C (+14 °F to +140 °F) |
|---|---|
| Atsparumas drėgmei veikimo metu | 10% to 95% |
| Energijos šaltinis | 9 to 32 VDC |
| Energijos suvartojimas | Standby: ≤ 0.5 W,Full load: ≤ 70 W,Note: Without peripheral and storage media: ≤ 20 W |
| Veikimo metodas | Mouse, IR remote control, Web control, and touchscreen |
| Matmenys (W × D × H) | 206 × 219 × 60 mm (8.1 × 8.62 × 2.36 inch) |
| Svoris (be atminties talpyklos) | 1.6 kg (3.53 lb) |
Pozicija
| GNSS | GPS (Global Positioning System) & GLONASS (Global Navigation Satellite System), 1 × Rosenberger antenna |
|---|
Užkodavimo/iškodavimo parametrai
| Vaizdo suspaudimas | H.264/H.265 |
|---|---|
| Užkodavimo raiška | Main stream: 4 MP/3 MP/1080p/720p/WD1/4CIF Sub-stream: 720P/4CIF/2CIF/CIF |
| Kadrų dažnis | PAL: 1 to 25 fps, NTSC: 1 to 30 fps; |
| Garso suspaudimas | G.711/G.722.1 |
| Srauto tipas | Video, Video & Audio |
| Garso bitų greitis | 16 Kbps |
| Dvigubas srautas | Supported |
PoE
| PoE sąsaja | 4 × RJ45 10M/100M self-adaptive PoE interface |
|---|---|
| Maks. suvartojimas | 45 W |
